TRIMAX TXM+ Laser Imaging Film

TRIMAX TXM+ Laser Imaging Film is a photothermographic, high-resolution gray-scale film that may be applied in continuous-tone medical imaging tasks. It offers fine detail and accurate image rendition with excellent diagnostic visualization, making it suitable for various imaging modalities like mammography, computed tomography (CT), digital subtraction angiography (DSA), magnetic resonance imaging (MRI), nuclear medicine, ultrasound, computed radiography (CR), digital radiography (DR), and digitized film images.

Coated on a blue, approximately 7-mil polyester base support, the film is infrared-sensitive and can be employed with TRIMAX Laser Imaging Systems. TRIMAX TXM+ Laser Imaging Film is available in several sizes to meet all requirements for imaging.

Undeveloped Film:

Store at 4–24°C (39–75°F).

Maintain relative humidity between 30% and 50%.

Shield from x-rays, gamma rays, or other penetrating radiation.

Developed Film:

Avoid prolonged exposure to strong light or heat (≥54.4°C or 130°F) for more than three hours.

Store in sleeves when not being reviewed.

Can be left on a light box for more than 24 hours, if light box is not very hot (≥49°C or 120°F).

Commercially Optimized Title:

TRIMAX TXM+ High-Resolution Laser Imaging Film for Medical Applications

Part of the Medelem X-Ray Films range – medical imaging equipment supplier for Africa, CIS and MENA.

TRIMAX TXM+ High-Resolution Laser Imaging Film for Medical Applications

The TRIMAX TXM+ Laser Imaging Film is a high-resolution photothermographic gray-scale medical imaging film for continuous-tone medical imaging applications. It delivers superior diagnostic visualization with fine detail, crisp image rendition, and cool image tone, and is adaptable to a number of imaging modalities.

Key Features:

High-Resolution Imaging: Delivers superb diagnostic visualization with fine detail and crisp image rendition.

Infrared-Sensitive: Compatible with TRIMAX Laser Imaging Systems.

Flexible Applications: Suitable for Full Field Digital Mammography (FFDM), CR-Mammography, computed tomography (CT), digital subtraction angiography (DSA), magnetic resonance imaging (MRI), nuclear medicine, ultrasound, computed radiography (CR), digital radiography (DR), and digitized film images.

Rugged Construction: Coated on blue, approximately 7-mil polyester support base.

Storage and Handling Conditions:

Undeveloped Film:

Store at 4–24°C (39–75°F).

Maintain relative humidity at 30% to 50%.

Avoid x-rays, gamma rays, or other penetrating radiation.

Developed Film

Do not subject to prolonged intense illumination or excessive heat (≥54.4°C or 130°F) for more than three hours.

Keep in sleeves when not under review.

May remain on a light box longer than 24 hours if the light box does not overheat (≥49°C or 120°F).

Handling Instructions:

Clean, dry, and lotion-free hands must be used.

Handle film carefully by edges to avoid physical stresses such as pressure, creasing, or buckling.
Tri-Max CAFS Fire Suppression Products

Shelf Life: TRIMAX TXM+ Laser Imaging Film retains its shelf life of 30 months when stored under recommended conditions.
