Carestream Flexible Phosphor Screen GP2

CARESTREAM FLEXIBLE PHOSPHOR SCREEN GP2

Screen GP2

Carestream Flexible Phosphor Screen GP2 is a groundbreaking X-ray screen that delivers high-quality images at low radiation doses.

Benefits:

  • Reusable: Unlike X-ray film, the GP2 screen can be used thousands of times, which reduces costs and minimizes waste.
  • Fast image acquisition: CR systems with the GP2 screen allow images to be acquired much faster than film-based systems, which improves workflow efficiency.
  • High image quality: Images acquired with the GP2 have a wide dynamic range and high spatial resolution, providing more accurate diagnostics.
  • Low radiation dose: CR systems with GP2 allow images to be obtained at a lower radiation dose to the patient compared to film-based systems.

Part of the Medelem Imaging Plate range – medical imaging equipment supplier for Africa, CIS and MENA.

Please log in to see pricesRegister / Log inSend a request

Additional information

Weight N/A
Dimensions N/A
SIZE

14×17"in (35x43cm), 10×12"in (25X30cm), 24x30cm, 8×10"in (20x25cm)
Plate storage humidity, %

25-76
Plate storage temperature, °C

10°-40°
Type of examination

General radiology, Mammography

Product Details

Carestream Flexible Phosphor Screen GP2: Next-Generation X-ray Imaging

Plate GP2 is a groundbreaking X-ray screen designed to deliver high-quality images at low radiation doses.

Benefits:

  • Reusable: The GP2 screen can be used thousands of times, which reduces costs and minimizes waste.
  • Fast image acquisition: CR systems with the GP2 screen allow images to be acquired much faster than film-based systems, improving workflow efficiency.
  • High image quality: The GP2 provides a wide dynamic range and high spatial resolution, enabling clinicians to make more accurate diagnoses.
  • Low radiation dose: CR systems with the GP2 allow for reduced radiation exposure to patients compared to film-based radiography.

Technical Specifications:

  • Material:
    • Base: Polyester film
    • Phosphor layer: Barium strontium sulfate (BaSrSO4)
  • Storage temperature: -20°C to +50°C
  • Size: Available in various sizes, from 10x12 cm to 43x43 cm
  • Thickness: 0.4 mm
  • Weight: 0.25 kg/m2
  • Resolution: 200 lines/mm
  • Dynamic range: > 300
  • Sensitivity: 150 μR/mR
  • Erasure time: < 1 second
  • Lifespan: > 100,000 erase/write cycles

Additional Features:

  • Flexibility: The screen can be flexed up to 180°
  • Waterproof: The screen is waterproof
  • Compatibility: Compatible with Carestream CR systems

Carestream Flexible Phosphor Screen GP2 is the ideal solution for healthcare facilities that want to:

  • Enhance the quality of X-ray imaging
  • Reduce radiation exposure to patients
  • Improve workflow efficiency
  • Lower costs
